Used storage tank
- Material: HDPE
- Condition: Used
- Volume (in litres): 6000 L
- In stock: 1
| General | |
|---|---|
| Item number | 10.45.WP.01 |
| Material | HDPE |
| Number | 1 |
| Capacity (Liters) | 6000 |
| Type tank | Storage tank |
| Fixation | - |
| Model of the tank | Vertical |
| Shape of the tank | Cylindrical |
| Bottom | Flat bottom |
| Tank model | Single wall |
| Number lifting lugs | 2 |
| Number of manhole | 1 |
| Position of manhole (s) | Top |
| Dimensions of manholes | dia 370mm |
| Tank with total drain? | No |
| Type of outlet (s) | flens |
| Diameter of outlet (mm) | DN32 |
| locality | B-7711 Belgium |
| Last application | Agriculture |
| Provision tank cleaning | None |
| Weight (kg) | 350 |
| Condition | Used |
| Type plate manufacturer | No |
| Construction data available | No |
| Drawing 1 | t1036WP02.pdf |
| Top side | |
|---|---|
| Configuration top-side | Closed |
| Detail closed top side | Conical bottom |
| Thickness closed dome (mm) | 12 |
| Dimensions | |
|---|---|
| Cylinder Thickness (mm) | 12 |
| Bottom thickness (mm) | 20 |
| Periphery (mm) | 6250 |
| Cylindrical length (mm) | 2000 |
| Total height (mm) | 2300 |
| Length (mm) | 2190 |
| Diameter tank (mm) | 1965 |
| Width (mm) | 2070 |
| Insulation | |
|---|---|
| Insulation | No |
| Remarks | |
|---|---|
| Description (EN) | collapsed conical roof --- openings in manhole cover --- opening above outlet |
